SPECIFICATION:
|
Standard Capicity |
50，100，150，250 lb | ||
| Recommended Excitation | 10 V AC/DC | Compensated Temp.Range | -10℃to + 40℃ |
| Maximum Excitation | 15 V AC/DC | Operating Temp.Range | -20℃to + 60℃ |
| Output at Rated Load | 3mV/V±10％ | Zero Balance | ±1％ |
| Combined Error | 0.03％ | Input Resistance | 385±5Ω |
| Non Repeatability | 0.02％ | Output Resistance | 350±3Ω |
| Creep (20 minutes) | 0.03％ | Insulation Resistance(50VDC) | ＞5000 MΩ |
| Zero Return (20 minutes) | 0.03％ | Deflection at Rated Load | ＜0.5mm |
| Temp.Effect/10℃ on Span | 0.015％ | Safe Overload | 200％ |
| Temp.Effect/10℃ on Zero | 0.026％ | Ultimate Overload | 300％ |
